AEG CCE84751XB Built-in induction hob + Extractor

Features

Bridge XT: 2 in 1 hob/extractor combination, recirculation version

auto function

Electronic regulation

OptiHeat Control - 3-level residual heat indicator

Electronic displays for all 4 cooking zones

4 induction cooking zones

Direct Control cooking zone activation

Power function for each cooking zone

minute minder

eco timer

Timer for all cooking zones

Off Sound Control

child lock

locking function

Power-dependent automatic switch-off

ventilation function

Installation: OptiFit Frame - stainless steel frame

inverter motor

3 power levels + 1 intensive level

Visual saturation indicator - grease filter

2-in-1 filter - combination activated carbon and grease filter to eliminate odors and grease; dishwasher safe

perfomance

Type of hob: induction cooking zones

Air flow at max. output in exhaust air mode in m³/h: 500

Recirculation mode: yes

Fluid dynamic efficiency class: A

Fluid dynamic efficiency: 32.4

Air flow at min. performance in exhaust air mode in m³/h: 270

Air flow at intensive level in exhaust air mode in m³/h: 630

Front left cooking zone (kW / Ø cm): 2300/3200W/210mm

Cooking zone rear left (kW / Ø cm): 2300/3200W/210mm

Front right cooking zone (kW / Ø cm): 2300/3200W/210mm

Cooking zone rear right (kW / Ø cm): 2300/3200W/210mm

device data

Device width (mm): 796

Installation dimensions: 215x780x490

Color: Black

Installation height (mm): 215

Device depth (mm): 516

Cut-out width (mm): 780

Cut-out depth (mm): 490

Gross weight (kg): 26.68

Net weight (kg): 20.8

Packing Height (mm): 540

Packing width (mm): 935

Packing Depth (mm): 619

energy values

Air flow at max. output in recirculation mode in m³/h: 465

Annual energy consumption (kWh/year): 28.8

Grease separation class: B

Degree of fat separation (%): 85.1

Noise level at min. output in exhaust air mode in dB(A): 49

Noise level at max. output in exhaust air mode in dB(A): 64

Noise level at intensive level in exhaust air mode in dB(A): 70

Air flow at min. output in recirculation mode in m³/h: 250

Air flow at intensive level in recirculation mode in m³/h: 585

Noise level at min. output in recirculation mode in dB(A): 54

Noise level at max. power in recirculation mode in dB(A): 70

Off mode power consumption (W): 0.49

Connection value (Watt): 7350

Voltage: 220-240V/400V2N

Technical specifications

Product number (PNC): 949 597 951

Design: ComboHob: 2 in 1 hob/extractor combination

Type of operation: Touch on glass

EAN number: 7332543838646

Exhaust mode: no

Energy efficiency class: A+ (spectrum A+++ to D)
